China Factory Supplies Magnetic Filter for water

  • Product introduction
Magnetic Filter can be used to remove iron pollutants (e.g. rust and scrap iron) and other iron impurities. It can effectively improve the quality of products on production line and protect key equipment from the destruction by iron particles.

MS Iron Remover is designed with optimal magnetic circuit and distribution of magnetic bar by using 3D finite element analysis method. The whole device is made of stainless steel. The magnetic bar is made of NdFeB superpower permanent magnetic material that is manufactured with updated technology. With the peak intensity of the surface magnetic field reaching 12000 Gauss, it is the top-class permanent magnetic material in the world. The roof cover is designed as quick-open type or sanitary clamp.

Application area

Applicable liquids: Fluids containing micro amount of iron, cobalt and nickel particles.
Main separation function: Catching iron, cobalt and nickel particles.
Separation type: Magnetic trap.

Specifications
Sub-series  MS3-MS24
Caliber  DN25-DN600
 Magnetic strength(Gauss) 6000  -  12000
 Proper temperature(℃)   <80,High temperature type can be customized
 Shell material  304316L
 Design pressure(MPa) 0.6-1.0 other pressures can be customized


For more product information, please consult technical engineer,Tel:15216604123
